Textile Backed Screen Surfaces
In this group, the reflective surface is laminated to a
woven textile base. The screen surface hangs suitably flat
because of the stability of the material and the weight of
the bottom dowel. Good for all types of projection. Commonly
used for single lens video projection, as well as for CRT
video and data-graphics projection.
Fiberglass Matt White
The standard to which all other screen surfaces are
compared. Matt white vinyl reflective surface laminated to
tear-resistant woven fiberglass. A matt white surface
diffuses projected light in all directions, so image can be
seen from any angle. Provides accurate color rendition as
well as superior clarity. Recommended for use with all high
light output projection devices. Requires control of ambient
light in the audience area. Washable, flame and mildew
resistant. Seamless in all standard sizes through 10’ high.
Care and Maintenance: Clean surface with a
solution of mild dishwashing liquid diluted with warm water.
Sponge the surface, rinse with clear water and blot dry. Do
not use cleaning solvents or abrasives.
Panamax
(Available only on screens larger than 10' x 10'.) Seamless
matt white material for large roller operated
screens-through 16' wide. Panamax has excellent dimensional
stability. Washable. Most motorized screens with Panamax are
not UL listed.
Care and Maintenance: Clean surface with a
solution of mild dishwashing liquid diluted with warm water.
Sponge the surface, rinse with clear water and blot dry. Do
not use cleaning solvents or abrasives.
Glass Beaded
Spherical glass beads embedded in surface provide brighter
on-axis viewing than matt white, within a narrower viewing
cone. All glass beaded surfaces have some loss of clarity
and perform best with table-mounted projectors. Flame and
mildew resistant; cannot be cleaned. Seamless in all
standard sizes through 10’ high.
Care and Maintenance: Clean surface with a very
soft brush or cloth and carefully dust the surface. Do not
use soap, water, solvents or abrasives.
AT1200
The most innovative and versatile acoustically transparent
screen material. Similar in gain performance to standard
matt white and does not require tensioning for flatness.
Acoustical properties comparable to the finest speaker
grille cloth. Washable, flame and mildew resistant. Not
recommended for screens smaller than 80" wide when used with
LCD or DLP projectors. Available in sizes through 72" x 96"
or 10' diagonal. (Not available on screens less than 80"
wide.)
Care and Maintenance: Clean surface with a solution
of mild dishwashing liquid diluted with warm water. Sponge
the surface; rinse with clear water and blot dry. Allow
screen to air dry overnight in down position. Do not use
cleaning solvents or abrasives.
AT Grey
Offers the acoustical properties of our popular AT1200,
while providing the best optical qualities of both Matt
White and High Contrast Grey. It is unique in that it offers
both a 180° viewing cone and the vivid color contrast
associated with high contrast grey materials. Washable,
flame and mildew resistant. Gain of 0.8. Available in sizes
through 72" x 96" or 10' diagonal. Not recommended for
screens smaller than 80" wide when used with LCD or DLP
projectors. (Not available on screens less than 80" wide.)
Care and Maintenance: Clean surface with a solution
of mild dishwashing liquid diluted with warm water. Sponge
the surface, rinse with clear water and blot dry. Allow
screen to air dry overnight in down position. Do not use
cleaning solvents or abrasives.
High Contrast Grey
High Contrast Grey: Grey textile-backed surface offers
excellent resolution while enhancing the blacks of LCD and
DLP projected images, even as whites and lighter colors are
maintained. Performs well in ambient light. Lower gain of
0.8 allows use with even the brightest projectors. Available
on most non-tensioned motorized and manual screens, in sizes
through 8' high, without seams. Viewing cone of 180°.
Care and Maintenance: Clean surface with a
solution of mild dishwashing liquid diluted with warm water.
Sponge the surface, rinse with clear water and blot dry. Do
not use cleaning solvents or abrasives.
100% Vinyl Screen Materials
These screen surfaces are tensioned vinyl with no backing.
Draper offers motorized, crank-operated and permanently
tensioned screens with built-in tensioning systems. The
surface is stretched perfectly flat, resulting in better
picture quality. Flatness is always desirable, particularly
for video or data-graphics projection.
HiDef Grey
A grey front projection surface that provides greater
contrast and black reproduction than standard surfaces, with
a lower gain to handle today's super-bright projectors. The
grey color enhances color contrast and black levels in the
projected image and also allows for more ambient light in
the audience area than traditional surfaces. Available on
all tab-tensioned and permanently tensioned screens, in
sizes through 96" x 96", or 6' high in greater widths.
Care and Maintenance: Clean surface with a
solution of mild dishwashing liquid diluted with warm water.
ARMOR ALL® Multi- Purpose Cleaner may also be used. Remove
stubborn stains with a solution of rubbing alcohol and
water. Do not allow any cleaners to be absorbed by the
fabric. Do not use cleaners which contain abrasives or wax.
M1300
The perfect matt white diffusing surface. Extremely broad
light dispersion and spectral uniformity. Panoramic viewing
angle and true color rendition. Recommended for use with any
type of projector in rooms where the light level can be
reasonably controlled. Washable.
Care and Maintenance: Clean surface with a
solution of mild dishwashing liquid diluted with warm water.
ARMOR ALL® Multi- Purpose Cleaner may also be used. Remove
stubborn stains with a solution of rubbing alcohol and
water. Do not allow any cleaners to be absorbed by the
fabric. Do not use cleaners which contain abrasives or wax.
M2500
A high-contrast front viewing surface, with excellent
resolution and high gain. For data-graphics projectors
producing through 1000 ANSI lumens. M2500 tolerates a higher
ambient light level than most other front projection screen
surfaces. Available on all permanently tensioned and
tab-tensioned screens.
Care and Maintenance: Clean with a very soft
brush or cloth and carefully dust the surface. Do not use
soap, water, solvents or abrasives.
Cineflex
A neutral grey vinyl for rear projection. Cineflex has high
resolution and excellent contrast, even in lighted rooms.
For use with any type of projection equipment.
Care and Maintenance: Gently clean this rear
projection material with a diluted solution of mild
dishwashing liquid and warm water. ARMOR ALL® Multi-Purpose
Cleaner may also be used. It is best to lay the surface flat
during cleaning. Do not use cleaners which contain abrasives
or wax.
d
Flexible Matt White
Pliable matt white material for use in our portable folding
screens. It can be stretched, folded and restretched
repeatedly without damage. Flexible matt white is an
excellent matt white material with a gain of 1.0 and a
viewing cone of 180°.
